PV Modules

The market for commercial crystalline silicon (c-Si) solar modules has been ruled for decades by the well-established ribbon-interconnected Al-BSF solar cells, making their metrology and in particular the current-voltage measurement well defined and reproducible.

Bifaciality can be implemented by varieties of architectures for solar cells, modules and in addition there are even many more applications on system level. This makes bifaciality a complex technology. Currently there is some confusion in the PV community what bifacial gains can be expected and how these transfer to the cost reduction and lowering the LCOE of the system. In this article we will describe how bifacial gains are defined, what bifacial gains can be expected and what this means for real applications.

Bifacial PV technology raises new challenges for the characterization and modelling of solar cells and modules, as well as for the yield predictions of power plants, as the contribution of the rear side can significantly affect the performance of these types of device.

LONGi, Jolywood and many other large PV manufacturers claim that bifacial mono c-Si technology is the future. Since 2015, bifacial PV installations have been entering multi- MW installation levels, and are expected to enter multi-GW levels in 2018.

To guarantee the long-term competitiveness of the PV industry, the cost of PV power generation ($/kWh) must be continuously reduced. Such reduction can be achieved in two ways: 1) by improving PV module performance (efficiency, annual energy yield, reliability); 2) by reducing manufacturing costs ($/Wp).

Understanding power losses in technical systems is vital to improve products in every industry and photovoltaic modules present no exception. Losses in solar modules are caused by optical and electrical effects or are determined by simple module geometry through inactive areas.

In recent years, potential-induced degradation (PID) has been recognized as a serious reliability issue for large PV systems, potentially causing efficiency losses of more than 90%, and even failures [1–4]. Such large decreases in efficiency may require the modules in the system to be replaced after just a few years’ operation. This has motivated a substantial research effort in the PV community, leading to a better understanding of the phenomenon, as well as to a range of mitigation strategies. A recent publication by Luo et al. gives a comprehensive overview of this research [5].

This paper focuses on the technical progress of high-efficiency crystalline silicon solar cells and modules, specifically with regard to passivated emitter and rear cell (PERC) processes, module description and light induced degradation (LID) data. Through appropriate optimizations of the solar cell and module processes, the cell efficiency achieved in mass production is 21.3%, with module power exceeding 300W. To solve the LID problem, hydrogenation technology developed by UNSW is used, bringing the cell LID rate down to below 1%.

This paper presents a summary of the status of bifacial PV in respect of the technology in mass production, the installed PV systems, and the costs relating both to module production (cost of ownership – COO) and to electricity (levelized cost of energy – LCOE). Since the first bifacial workshop, organized by ISC Konstanz and the University of Konstanz, in 2012, many things have changed. Bifacial cells and modules have become cost effective, with installed systems now adding up to more than 120MWp and the technology becoming bankable. Large electricity providers have recognized the beauty of bifacial installations, as the lowest costs per kWh are attainable with these systems. The authors are sure that by the end of 2017, bifacial PV systems amounting to around 500MWp will have been installed, and that by 2025 this type of system will become the major technology in large ground-mounted installations.

Even though it is now more than five years since potential-induced degradation (PID) began to proliferate, and despite the fact that solutions are under development, it is currently still the most discussed mode of degradation associated with cracking in PV modules.
