Climate change, oil shortage, green energy, energy security – these are some of the global `mega´-topics currently dominating the agenda in the news, in politics and in private lives. One of the industries that has most profited from the ever-growing consciousness about the need to de-carbonize current energy use is the photovoltaic industry. With this economic background, the photovoltaic industry has experienced impressive growth rates in the last decade and is expected to grow at 30% per year over at least the next couple of years. Since its upswing, it has become a multi-billion dollar industry and subject to speculation on stock exchanges worldwide.

The rapid growth of the solar energy industry owes its success to the development and production of mono- and multi-crystalline solar cells. This growth has been limited in recent years due to the lack of available supply of polysilicon, the key raw material for making the wafers that serve as the basis of the solar cell. As a result of this limitation, the price of polysilicon has increased dramatically and this has led to significant new and planned capacity expansions. These new capacity expansion announcements have been highly publicized, with little additional outside focus on other chemicals and materials.

The photovoltaic industry was once, and for quite some time, the unappreciated renewable technology. Perceived as too expensive without subsidies to reduce the price of ownership, and sometimes as an energy choice primarily for environmental zealots, the industry has continued, nonetheless, to grow at a compound annual rate of 34% over the past 30 years. Growth at this rate would be envied by any industry, and certainly deserves recognition, particularly as it has come with significant problems and has been extremely difficult to achieve. Now, with worldwide consensus on global warming along with sufficient evidence that fossil fuels are rapidly depleting, solar electricity is finally earning some respect - but the industry still has perception problems to solve.

Si etch processes are vital steps in Si solar cell manufacturing. They are used for saw damage removal, surface texturing and parasitic junction removal. The next generation of Si solar cells, featuring thinner wafers and passivated rear surface, will pose more stringent demands on those steps. Surface decoupling (achieving different surface treatments on the front and the rear) has to be achieved while minimizing Si consumption. Plasma texturing is an emerging technique that appears very promising in that respect, as efficiencies as high as 17.4 % have been achieved on screenprinted multicrystalline Si solar cells incorporating this process.

Many readers will equate SEMI with the SEMICON trade shows around the world, business and technical conferences, EHS and advocacy initiatives and, most of all, industry standards. Currently, SEMI has close to 2,000 member companies, about 20% of which are active in the photovoltaic sector. These companies form a community called PVGroup – a community that addresses opportunities and obstacles collectively, bringing low-cost PV technology and sustainable clean energy to the world. SEMI is supporting this segment by expanding our key competencies – shows, standards, advocacy, and market research – into this new space.

Every day, mankind consumes as much energy as it took the earth 1,370 years to store. The International Energy Agency estimates that by the year 2030, worldwide electricity consumption will have increased annually by approximately 2.4%. City Solar AG is seeking to increase renewable energy stocks through grid-connected solar power utilities. As one of the leading producers of large-scale photovoltaic plants, City Solar is uniquely placed to give us a better understanding of how these plants are put together.

The next two years will be crucial in determining the market viability and future of what many see as the most promising thin-film photovoltaics technology: copper indium gallium (di)selenide (CIGS) and its gallium-free cousin, CIS. With potential conversion efficiencies just below that of crystalline silicon PV, low-cost manufacturing strategies offering a chance to reach sub-dollar-per-watt manufacturing costs on both glass and flexible modules, and applications ranging from utility- and industrial-scale farms to building-integrated commercial and residential uses, the quaternary compound has a large grid-parity upside - if the very real challenges of scaling production to commercial volume can be met.

Until recently, Solyndra had been one of the stealthiest thin-film photovoltaics operators, its glistening, prominently logoed headquarters building reminding tech-savvy commuters plowing up and down the I.880 corridor near Fremont, CA, of how little they knew about the company. But Solyndra has finally let the sunshine in and come out of the closet — even if it hasn't quite changed some of its stealthy ways. After a well-planned media and analyst rollout, the public knows that for this copper-indium-gallium-(di)selenide (CIGS) thin-film PV manufacturer, the world — or at least its solar-module form factor — is not flat. Like many TFPV purveyors, Solyndra loves glass as a substrate, but the company's meter-long CIGS-coated cylindrical modules look like a fluorescent light-bulb tube, not just another rectangular slab of the smooth stuff.
